2024 Focus IZALCO MAX DISC 9.8 Ultegra Di2
Description
- MAX AERO CARBON FRAME (865 G)
- ELECTRONIC SHIMANO ULTEGRA DI2 2X12 SHIFTING
- DT SWISS ERC1600 CARBON WHEELS
MAKES YOU FASTER
AERO GAINS
The refined and wind tunnel-approved NACA-shapes (National Advisory Committee for Aeronautics) make our frame highly aerodynamic. At the same time, the frame only weighs 865 g for frame size M with an additional 400 g for the fork. Our C.I.S. road stem hides the cables below the stem. It also comes with an integrated bike computer mount for both Wahoo and Garmin.
7 SIZES FOR A PERFECT FIT
The IZALCO MAX is available in seven sizes. In combination with the stem, which we offer in six lengths from 70 to 120 mm, it really does have all the sizes for each and every one of you.
EFFORTLESS HANDLING AND MAXIMUM STIFFNESS
To enable you to get that extra power on the road, the bottom bracket is optimised for stiffness, and the fork for lateral stiffness. Together with a bold geometry for easier cornering, especially at high speeds, the IZALCO MAX is the road bike for all ambitions.
| FRAME | MAX technology carbon, disc, BB86, 142x12 mm thru axle, flat mount 160/140 mm, internal cable routing |
| FORK | MAX technology carbon, integrated cable routing, disc, 100x12 mm, flat mount |
| SHIFTER | Shimano Ultegra R8150 Di2, 12-speed |
| FRONT DERAILLEUR | Shimano Ultegra R8150 Di2, 12-speed |
| REAR DERAILLEUR | Shimano Ultegra R8150 Di2, 12-speed |
| SPROCKET | Shimano Ultegra CS-R8100, 12-speed |
| CHAIN | Shimano XT CN-M8100, 12-speed |
| CRANKSET | Shimano Ultegra FC-R8100, 12-speed |
| TRANSMISSION OF DRIVE | Front: 52/36T | Rear: 11-30T |
| BOTTOM BRACKET | Shimano Pressfit Road BB86 |
| HANDLEBAR | Easton EC70 Aero, carbon Drop: 125 mm, Reach: 80 mm |
| STEM | FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium, with Garmin / Wahoo-Mount |
| HEADSET | ACROS IS 52/286-IS52/40 (ICR), FOCUS integrated C.I.S. |
| SADDLE | fi'zi:k Vento Argo R5 |
| SEATPOST | FOCUS Aero Carbon, D-shape, 350 mm Set-back: 15 mm |
| BRAKE CALIPER | Shimano Ultegra BR-R8170 |
| BRAKE LEVER | Shimano Ultegra R8170, Di2 |
| BRAKE | Disc |
| WHEELSET | DT Swiss ERC1600, carbon, 622-22, 12x100 mm / 12x142 mm, 45 mm height |
| TIRES | Vittoria Corsa, Next TLR, 28-622, Folding |
| GEARS | 24 |
| BIKE WEIGHT IN KG. | 7.75 kg |
| SIZE | XXS, XS, S, M, L, XL, XXL |
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
